Kylindros Reflector
A lensed reflector system with three optic options drives the exceptionally low-glare Kylindros reflector. Designed with modular, replaceable componentry, this fitting also boasts excellent ingress protection and ruggedness. From task lighting to throwing light from high ceilings, this
fitting is sure to handle almost any design requirement and do so with style.
APPLICATIONS
Office
Residential
Hospitality
Public buildings
Receptions
SPECIFICATIONS
Power Factor:
Electrical Input:
AC 220-240V / 50-60 Hz
FEATURES
Warranty:
5 years
Construction:
Stainless Steel (316 SS), Polycarbonate (PC)
Metal Finish:
Polished Aluminium
Standard Mounting:
Cieling Mounted
Standard Mounting:
Suspended, Wall-mounted
Life Prediction (hrs):
L80 > 102,000 hrs
Ingress Protection:
IP65
Impact Protection:
IK10
| PRODUCT CODE | DIMENSION (mm) | POWER | Luminous Flux | Optic/Beam | Colour Temperature | Colour Rending Index |
|---|---|---|---|---|---|---|
| EKY12S36W8040R3x6 | 1130 x 70 mm | 36 W | 3240 lm - 4140 lm | 30ᵒ, 50ᵒ, 30ᵒx60ᵒ | 4000K | ≥ 80 |
| EKY12S36W8040R30 | 1130 x 70 mm | 36 W | 3240 lm - 4140 lm | 30ᵒ, 50ᵒ, 30ᵒx60ᵒ | 4000K | ≥ 80 |
| EKY12S36W8040R50 | 1130 x 70 mm | 36 W | 3240 lm - 4140 lm | 30ᵒ, 50ᵒ, 30ᵒx60ᵒ | 4000K | ≥ 80 |
| EKY14S48W8040R3X6 | 1395 x 70 mm | 48 W | 4320 lm - 5520 lm | 30ᵒ, 50ᵒ, 30ᵒx60ᵒ | 4000K | ≥ 80 |
| EKY14S48W8040R30 | 1395 x 70 mm | 48 W | 4320 lm - 5520 lm | 30ᵒ, 50ᵒ, 30ᵒx60ᵒ | 4000K | ≥ 80 |
| EKY14S48W8040R50 | 1395 x 70 mm | 48 W | 4320 lm - 5520 lm | 30ᵒ, 50ᵒ, 30ᵒx60ᵒ | 4000K | ≥ 80 |
